Microchip Product Selector Tool
by
Published on - 24th April 2010 17:53
Number of Views: 10993
Here is the new MAPS from Microchip. It makes it a little easier to select a device for your next project. Just adjust the sliders to the parameters you want, and click a few buttons. It takes a bit of time to load all the flash at the beginning, but then it is pretty quick.
http://www.microchip.com/productsele...tSelector.html
