32 bit seconds math (how do I include the upper 16 bits?)

[Heckler]

Hey Group,

I am using a Dallas Semiconductor DS2417 RealTimeClock
This little OneWire device simply starts counting seconds from where ever you tell it to start from (your date reference)
and gives the count back to you in a 4 byte 32bit register
With 32 bits the clock can count up for 136 Years before rolling over.

I need some help figuring out the math to convert the 32bit seconds to HH:MM:SS

My code below is able to do the conversion correctly on the first 16bit ok but fails to take into account the second 16 bits of the 32 bit data.
so after 18 hrs 12 min and 15 sec (65535 or $FFFF) it rolls over to zero.

I need to know how to deal with and include the upper 16 bits of the 32 bit data.

My code takes the lower two bytes (C&D) and combines them into a Word (CD)
and then does the math to convert to HH:MM:SS

But I am at a loss as to what to do with the upper 16 bits.

For now I am not interested in the DAYS, I am only wanting to keep track of a rolling 24 hour clock.
So I expect to just devide the seconds down and discard multiples of 24 hrs.

'=============================================================
'           Read OneWire Clock
'=============================================================
GetOWtime:
    owout OWTPin,%000,[$cc,$66]
	owin  OWTPin,%010,[owctrl,ByteD,ByteC,ByteB,ByteA]    'ByteD=LSB ByteA=MSB

	AB.byte1 = ByteA   'MSB
	AB.byte0 = byteB
	CD.byte1 = bytec
	CD.byte0 = byteD   'LSB
return      'with time


'=============================================================
' convert the one wire seconds count to HH:MM:SS
'=============================================================
HMS:
    owHH= CD/3600
    owMM= (CD/60)-(owHH*60)
    owSS= CD//60
return

I need help in figuring out what to do when the word "AB" starts counting above zero (which happens after the 18:12:15 point is reached (assuming I start from zero)

My plan is to start the clock at zero and store the actaul time I started the clock in a variable and add/subtract the stored time variable from the incrementing count to get the current real time.

I know there are other clocks that do all this for you (like the DS1307) but that one is I2C and I specifically need a One Wire solution.

thanks for any help or guidance you can give.

dwight

[Tabsoft]

Dwight,

You don't mention what PIC MCU you are using nor which version of Picbasic.

If your PIC and version of Picbasic supports Long variable types, that would be the simplest way to go. You of course would need to account for bit32 since PBPL uses Signed Long variable types and the DS2417 uses an Unsigned 32bit value.

Regards

[HenrikOlsson]

Hi Dwight,
Try the following:

ooDays VAR WORD
i VAR WORD
Temp VAR WORD

' This uses DIV32 by preloading the system variable it uses with
' the value we want to divide. To find out how many days has passed
' we divide the number of seconds with 86400 (number of seconds in a day).
' However, DIV32 only supports 16 bit divisor so we need to do the
' division in two steps, 21600 * 4 = 86400.

R0 = AB			' High word of seconds into system var
R2 = CD			' Low word of seconds into system var
ooDays = DIV32 21600	' Divide by 86400
ooDays = ooDays / 4

' Now we need to subtract 86400 seconds from the running time
' one time for each day that has passed. Since we're working with
' 16-bit words we need to this sort of "manually".
' 65536 + 20864 = 86400

For i = 1 to ooDays
  Temp = CD
  CD = CD - 20864

  IF Temp < CD THEN	' Did we underflow the low word?
    AB = AB - 1		' If so, decrement high word
  ENDIF

  AB = AB - 1            ' Subtract 65536
NEXT

' At this point ABCD contains anything from 0 to 86399 and we need to
' figure out how many "full hours" is in it. Because 86399 is more than
' what fits in a 16-bit word we're using DIV32 trick to divide the
' number of seconds by 3600 (number of seconds in an hour).

R0 = AB			' High word of what's left in seconds into system var
R2 = CD			' Low word of what's left in seconds into system var
ooHH = DIV32 3600	' Divide by the number of seconds in an hour

' Subtract 3600 from the running time, one time for each hour.
For i = 1 to ooHH
  Temp = CD
  CD = CD - 3600

  IF Temp < CD THEN	' Did we underflow the low word?
    AB = AB - 1		' Subtract one from high word.
  ENDIF

' Now, we're down to minutes and there can be no more than 3599 seconds left
' so we can easily handle it with just the low word and normal math
ooMM = CD / 60

' And finally we can get the seconds by getting the reminder.
ooSS = CD // 60

It's based on a piece of code I originally wrote for doing SNTP with W5100 chip. SNTP basically gives you the numner of seconds passed since 1900-01-01 00:00:00 so I stripped out the year, leapyear, and month stuff and adopted it to your variables. I have not verified the above to be working.

/Henrik.

[Heckler]

@TABSoft

Sorry, I should have posted that info...

Using PBP 3
the PIC is 16F690 (but I also want to be able use the newer 16F1828)

I had thought about using Long's but I've never used PBPL and what little info is in the manual is very vague.
What does it take to use a Long?? and invoke PBPL?

I haven't done much searching on PBPL yet. I'm going to give the code that Henrik (thanks!!) posted and see what it does for me.

[Heckler]

Wow Henrik!!

You write amazingly good "unverified" code!
You did miss one "NEXT" down at the end.
I had to change your ooHH, etc. variables to match mine (owHH)

But it is working beautifully!

'=============================================================
' convert the one wire seconds count to HH:MM:SS
'=============================================================
HMS:

owDays VAR WORD
i VAR WORD
Temp VAR WORD

' This uses DIV32 by preloading the system variable it uses with
' the value we want to divide. To find out how many days has passed
' we divide the number of seconds with 86400 (number of seconds in a day).
' However, DIV32 only supports 16 bit divisor so we need to do the
' division in two steps, 21600 * 4 = 86400.

R0 = AB			' High word of seconds into system var
R2 = CD			' Low word of seconds into system var
owDays = DIV32 21600	' Divide by 86400
owDays = owDays / 4

' Now we need to subtract 86400 seconds from the running time
' one time for each day that has passed. Since we're working with
' 16-bit words we need to this sort of "manually".
' 65536 + 20864 = 86400

For i = 1 to owDays
  Temp = CD
  CD = CD - 20864

  IF Temp < CD THEN	' Did we underflow the low word?
    AB = AB - 1		' If so, decrement high word
  ENDIF

  AB = AB - 1            ' Subtract 65536
NEXT

' At this point ABCD contains anything from 0 to 86399 and we need to
' figure out how many "full hours" is in it. Because 86399 is more than
' what fits in a 16-bit word we're using DIV32 trick to divide the
' number of seconds by 3600 (number of seconds in an hour).

R0 = AB			' High word of what's left in seconds into system var
R2 = CD			' Low word of what's left in seconds into system var
owHH = DIV32 3600	' Divide by the number of seconds in an hour

' Subtract 3600 from the running time, one time for each hour.
For i = 1 to owHH
  Temp = CD
  CD = CD - 3600

  IF Temp < CD THEN	' Did we underflow the low word?
    AB = AB - 1		' Subtract one from high word.
  ENDIF
next
' Now, we're down to minutes and there can be no more than 3599 seconds left
' so we can easily handle it with just the low word and normal math
owMM = CD / 60

' And finally we can get the seconds by getting the reminder.
owSS = CD // 60

return

Thank you so much.
I preloaded the clock with 23:59:00 and it rolled over to 00:00:00 as expected!

Now to go digest and try and understand what you actually told my little micro-conntroller to do.

after all that is what we are doing when we write code "telling these little pieces of silicone" how and when to do something

thanks again!

I actually have two clocks and a DS18b20 on my little breadboard...
the I2C DS1307 and the onewire DS2417 (boy its a liittle guy) you can see it just below the LCD and on the PCB in the breadboard.

You can see the time from the DS1307 (blue PCB) on the top line
you can see the 4 bytes of seconds count from the DS2417 on the 3rd line
on the bottom line is the result of you conversion code.





Thanks

[HenrikOlsson]

Hi Dwight,
That's excellent news, glad I could help!
Sorry for the missing NEXT, I should have at least compiled it before posting but I was really short on time.

Regarding using LONGs. If you're using Microcode Studio as your IDE there's a checkbox in the View -> Compile and program options saying Use Compiler Long Words (18 series MCU Only). Tick that and you'll be compiling with LONGs enables. As the text says you have to use an 18F part so the 16F690 or 16F1828 will not work.

/Henrik.

[Heckler]

Sorry for the missing NEXT, I should have at least compiled it before posting but I was really short on time.

Henrik,
Please don't feel bad. I could only hope to quickly analyze someone elses code/project and toss out such a quick and good answer.

The value of forums like this is the willingness of folks like you, TABsoft and others to donate their time and talent to help others out.

The fact that you missed a "next" is trivial. The fact that you could understand my need and share a possible solution is the key.

I had looked at the DIV32 function in the PBP manual but could not understand how to apply it in my situation. The manual led me to believe that I first had to multiply two numbers. Which I did not need to do (or is that actually what one is doing by combining a LowWord and a HighWord??). ((don't think so... because FF x FF =FE01 not FFFF))

I did not know that one could pre-load the system variables manually (no mention of that fact in the manual) or which system variables would be involved (R0, R2)

[HenrikOlsson]

Hi Dwight,
No, that sort of info is not in the manual. I don't remember from where I got it but I'd be surprised if it wasn't from one of Darrels post.

Anyway, yes, normally what you do is multiply two 16bit number which results in a 32bit result then, imediately after, you execute the DIV32 which will divide that 32bit result by the 16bit divisor. The trick is to know that when you do the 16*16bit multiplication the result of that ends up in system variables R0 and R2. Once you know that there's nothing stopping you from manually loading those registers, the DIV32 function will not know the difference.

If you have a total of 1,125,000 seconds in your ABCD variable, looking at that in hex: 0011 2A88 what goes in R0 is 11h (17) and what goes on R2 is 2A88 (10888).
17*65536+10888=1,125,000.

I think there might be a possible issue with the code as posted. When the number of seconds passed is less than 86400 (one day) then owDays will be 0 and the FOR-NEXT loop subtracting 86400 seconds per day will execute 65535 times. I think the result will still be correct since it'll just wrap around but it may take a fair bit of time..... You might want to enclose that FOR/NEXT loop in an IF/THEN block checking if owDays > 0.

/Henrik.
