Simulator

[Darrel Taylor]

Yes, unfortunately the variables don't show when simulating directly in ISIS.

But if you run Proteus as a debugger in MPLAB 8 the watch window will show the variables.
MPLAB uses the same .cof file, so it's not currently known why they work in MPLAB and not ISIS.

Since you can have as many serial lcd's or virtual terminals as you want, it easier to just put a few statements in your program to spit out the variables at key points.
I don't really miss the variable window too much.

[AvionicsMaster1]

Boss says we might have some extra money and I'd like to order simulation software and an upgrade to PBP3.0.

Do you still recommend Proteus/ISIS when using PBP 3.0?

Thanks for your time.

[Darrel Taylor]

It's not very often that you won't see Proteus running on my computer.
It works great with PBP3.

I highly recommend getting the ARES (PCB layout) package with it.
I used to hate laying out PCB's, but it's almost enjoyable now.

Draw it, simulate it, lay it out, export gerbers, and order your proto's all in the same day.
