  1. #40
    Join Date
    Dec 2008
    Location
    Ploiesti, ROMANIA
    Posts
    582


    Did you find this post helpful? Yes | No

    Default

    My previous posts are wrong !
    This is what work good for me ( about 10 seconds) :
    Code:
    btn1:                   			'actionare buton up

      if but1=1 and rel2=0  then
               high rel1
               TMR1ON = 1
               pause 20

               while but1=1
               t1Count=T1Count+1
               call check
               wend
               IF LongPress THEN Stop_UP
               T1Count = 0
               pause 20

               while but1 = 0 and but2 = 0
               t1Count=T1Count+1
               call check
               if rel1=0 then
                  GOTO Btn1PressDone
               endif
               wend
        Stop_UP:
    idem for btn2
    and :
    Code:
              if vt > 270 o then
                          u=u+1
                          if u > 5 or T1Count > 100 then
      	              gpio.0=0
                          gpio.5=0
                          endif
                  pause 50
                  goto check
              else
                  u=0
    It's correct what I do ? Thanks !
    Last edited by fratello; - 23rd April 2010 at 18:00.
