https://www.picbasic.co.uk/forum/ MEL PICBASIC Discussion Community en Tue, 14 Apr 2026 03:27:23 GMT vBulletin 60 https://www.picbasic.co.uk/forum/images/misc/rss.png https://www.picbasic.co.uk/forum/ https://www.picbasic.co.uk/forum/showthread.php/27113-memory-full?goto=newpost Fri, 20 Mar 2026 11:33:32 GMT Hi all,

I have a application with the 16F882 and have add some data. But the memory is run over.
The '882 = 2048 words, "883 is only 4096 words.

I drive a LCD (1602) RS485 and some LEDs and buttons. Not really exciting.

But, I have 30 Hub's (0 to 29) to Open and Close and show on the LCD.

All 30 Open and Close strings are different.


After 8 Hub's in the program the memory ("882) runs out. Any advice?


Hub_ID = 0 ' Hub Open

high EN_RS485 ' Enable RS485
pause 5
hserout [0,2,0,16,67,45,255,15,222,3] ' Bus open
LCDOut $fe,$C0,"Hub ",dec Hub_ID, " is Open "
pause 5 ' Wait for last byte out
low EN_RS485 ' Disable RS485

pause 1000

high EN_RS485 ' Enable RS485
pause 5
hserout [0,2,0,16,67,47,255,15,220,3] ' Bus close
LCDOut $fe,$C0,"Hub ",dec Hub_ID, " is Close "
pause 5 ' Wait for last byte out
low EN_RS485 ' Disable RS485

pause 1000


' Do next Hub ]]> mel PIC BASIC Pro Gevo https://www.picbasic.co.uk/forum/showthread.php/27113-memory-full
